Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter

Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter

    • Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter
    • Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter
    • Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter
  • Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter

    Product Details:

    Place of Origin: Qingdao, China
    Brand Name: Lehler
    Certification: ISO9001:2015
    Model Number: LRT-90

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Negotiable
    Packaging Details: Plywood Case for Exporting Package
    Delivery Time: 7 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 10 pieces 10 work days
    Contact Now
    Detailed Product Description
    Name: Resin Retention Traps MOC: SS316L
    Slot: 0.8 Mm Application: Resin Retention
    Total Length: 90X105 Mm Structure: From Outside To Inside
    High Light:

    resin trap strainer

    ,

    wedge wire screen filter

    Media Retention Wedge Wire Resin Trap / Johnson Screens Resin Traps



    1. Why we need resin trap?

    Lehler wedge wire resin traps can can prevent loss of resins and keep the costly media in place.

    It is not only to prevent the loss of costly medias, but also to avoid damaging downstream equipment.

    Lehler design and manufacture resin traps according to the exact media particle size.

    Lehler design and manufacture resin traps resin in a wide variety of materials and sizes.



    2. Lehler resin trap Benifits?

    Lehler resin trap can prevent loss of resins and keep the costly media in place.
    Lehler resin trap can prevent the damage to the pipe fittings.
    Lehler resin trap can prevent the environmental damage.
    Lehler resin trap can prevent cross contamination of resins.



    3.Specification of Wedge Wire?

    Profile wire Support Rod
    0.75*1.5mm 2*3mm
    1.0*2.0mm 2*3mm
    2.0*3.0mm 3*5mm
    2.0*4.0mm 3*5mm
    3.0*5.0mm 3*5mm



    4.Details pictures of Resin traps:

    Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter 0

    Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter 1Resin Media Retention Resin Trap Strainer , LRT-90 Long Wedge Wire Filter 2
    5. Advantages of resin traps?

    1. Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
    2. Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
    3. Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
    4. High-precision slot opening: Minimum Slot opening is 20 microns.
