Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications

Certification
China Qingdao Lehler Filtering Technology Co., Ltd. certification
China Qingdao Lehler Filtering Technology Co., Ltd. certification
I'm Online Chat Now

Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications

Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications
Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications
Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications

Large Image :  Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications

Product Details:
Place of Origin: QINGDAO
Brand Name: Lehler
Model Number: LFN-D470

Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications

Description
New Application: Sizing For Paper Mill Inlet/Outlet Connection: Flanged/Threaded
Brush: Metal Brush Filter Precision: 100 Micron
Gasket: FPM Inlet Size: 1 1/2
Surface Finish: Mirror Polish Element: Wedge Wire Element

Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications

Product Description:

Our Automatic Self Cleaning Filters are equipped with auto-scrubbing straining elements that guarantee efficient and consistent filtration. These straining elements are designed to automatically clean themselves, ensuring that the filter is always working at its optimal level. This feature also eliminates the need for manual cleaning, which saves time and effort.

The metal brush that comes with this product is another standout feature. It is specifically designed to remove any debris or buildup from the filter. This improves the filter's performance, ensuring that it works seamlessly without any interruptions. The brush is durable and can withstand heavy usage.

The gasket is made of FPM, a material known for its excellent resistance to chemicals and high temperatures. This feature ensures that the filter is protected from corrosion and other damage caused by chemical exposure or heat.

The outlet of the filter is DN125, which is a standard size that can accommodate most applications. This feature makes the filter versatile and easy to install, making it a great addition to any facility.

Our Automatic Self Cleaning Filters also come with a power box that is EX-proof. This feature ensures that the filter is safe to use in hazardous environments, making it ideal for use in paper mills.

Overall, our Automatic Self Cleaning Filters are a reliable and efficient solution for your filtration needs. With its auto-scrubbing straining elements, metal brush, FPM gasket, DN125 outlet, and EX-proof power box, this product is sure to exceed your expectations. Contact us today to learn more about our Automatic Self-washing Strainers and how it can improve your filtration process.



Features:

  • Product Name: Automatic Self Cleaning Filters
  • Inlet/Outlet Connection: Flanged/Threaded
  • Surface Finish: Mirror Polish
  • New Application: Sizing For Paper Mill
  • Service: OEM
  • Brush: Metal Brush
  • Automated Screen Cleaning Equipment
  • Automatically Cleaned Sieves
  • Self-rinsing Filtration Devices
Technical Advantages


Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications 0
No disposable consumables:Save filter media cost and environment cost

Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications 1
Stainless steel structure:Variously materials, corrosion and rust prevention


Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications 2
High-precision slot opening: Min. Slot 20 microns




Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications 3
High automation degree:Which can work on-line continuously,no manual cleaning frequently
Specification

Product Model

Equipment Diameter

Equipment Height

Thickness

Filter Area

Slot

LFN-D159

200mm

500mm

3mm

0.1





Min. 0.02mm(20um)



LFN-D219

250mm

1000mm

3mm

0.2

LFN-D273

300mm

1450mm

4mm

0.5

LFN-D325

350mm

1600mm

4mm

0.6

LFN-D400

450mm

1700mm

6mm

0.7

LFN-D450

500mm

1750mm

6mm

0.9

LFN-D550

600mm

1850mm

6mm

2.0

LFN-D800

850mm

2000mm

6mm

2.5

Application

One of the best things about this filter is that it is a hands-free backflushing filter. This means that you don't have to manually clean it out, as the filter will clean itself automatically. The auto-scrubbing straining elements ensure that the filter stays clean and efficient, even under heavy use. This feature makes the Lehler LFN-D219 perfect for use in situations where manual cleaning would be difficult or impossible.

There are many different occasions and scenarios where the Lehler LFN-D219 Automatic Self Cleaning Filter would be the perfect choice. For example, it would be great for use in industrial applications where water filtration is necessary. It could also be used in commercial settings, such as restaurants and hotels, where water quality is important. Additionally, this filter would be useful in residential applications, such as in homes with well water or in areas with hard water.





Maximize Filtration Efficiency with Automatic Self Cleaning Filters for Industrial Paper Mill Sizing Applications 4

Customization:

Our self-cleaning automatic filters are manufactured in QINGDAO and are available for OEM service. The filters are designed with a wedge wire element for effective filtration. The power box is EX-proof, making these filters ideal for use in hazardous environments.

Our automatic self-cleaning filters are perfect for new applications, such as sizing for paper mills. These filters can be installed vertically or horizontally to suit your specific needs.



Support and Services:

The Automatic Self Cleaning Filters product comes with a comprehensive technical support and services package to ensure that our customers get the most out of their investment. The support and services include:

- On-site installation and commissioning

- Regular maintenance and servicing

- Troubleshooting and technical assistance

- Spare parts and consumables supply

- Upgrades and retrofits

Our team of experienced engineers is available to provide assistance and advice on any technical issues that may arise. We are committed to ensuring that our customers receive the best possible support and services to keep their Automatic Self Cleaning Filters operating at peak efficiency.



Packing and Shipping:

Product Packaging:

  • The automatic self cleaning filters are carefully packed in sturdy boxes to ensure safe transportation.
  • All components are properly secured and cushioned to prevent any damage during shipping.
  • The boxes are labeled with the product name, model number, and handling instructions for easy identification and handling.

Shipping:

  • We offer worldwide shipping for our automatic self cleaning filters.
  • Shipping costs vary depending on the destination and shipping method chosen by the customer.
  • Orders will be processed and shipped within 35 days of receipt of payment.
  • Customers will receive a tracking number once the order has been shipped.
  • Delivery times may vary depending on the destination and shipping method chosen by the customer.
