400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment

Certification
China Qingdao Lehler Filtering Technology Co., Ltd. certification
China Qingdao Lehler Filtering Technology Co., Ltd. certification
I'm Online Chat Now

400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment

400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment
400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment

Large Image :  400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment

Product Details:
Place of Origin: Qingdao, China
Brand Name: Lehler
Certification: ISO9001:2015
Model Number: WWS-550
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Plywood Case for Exporting Package
Delivery Time: 7 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1 piece 7 work days

400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment

Description
Name: Wedge Wire Screen Basket Material: 304L
Mesh: 400mesh Type: From Inside To Outside
Application: Waste Water Treatment Angle: 45 Degree
High Light:

wedge wire mesh

,

wedge wire filter

Inside To Outside Type Wedge Wire Screens for Basket Filter, Wedge Wire Screen Basket



1. What is Wire Screen?

Wire Screen is produced through the method of electric resistance welding,

wires with profile profiles are welded to support rod at 90 degrees.

The distance between two profile wires is the slot opening, which is the filtration rate.

Minimum slot is  20um.

The structure is FOTI(flow-out-to-in) & FITO(flow-in-to-out).



2.Specification of Wire Screen?

  • Minimum slot: 0.02mm(20um)
  • Mimimum diameter: 16mm
  • Maxmum Length: 6000mm
  • Perfect roundness
  • Very smooth wire surface
  • Profile wire size: 0.75x1.5mm, 1.0x2.0mm, 1.5x2.5mm, 2.0x3.0mm, 2.0x4.0mm, 3.0x5.0mm...
  • Support Rod size: 2.0x3.0mm, 3.0x5.0mm, 5.0x8.0mm
Profile wire Support Rod
0.75*1.5mm 2*3mm
1.0*2.0mm 2*3mm
2.0*3.0mm 3*5mm
2.0*4.0mm 3*5mm
3.0*5.0mm 3*5mm



3.Details pictures of Wire Screen



400 Mesh Wedge Wire Screen 45 Degree Angle For Basket Filter Waste Water Treatment 0

4. Application of wedge wire screen?

  • Coatings
  • Chemical
  • Petrochemical
  • Pulp and paper
  • Food and beverage
  • Solid-liquid separation
  • Waste water treatment
  • Mineral and aggregate processing

5. Advantages of wedge wire screen?

  • High-precision slot opening: Minimum Slot opening is 20 microns.
  • Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
  • Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
  • Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
