Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification

Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification
Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification

Large Image :  Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification

Product Details:
Place of Origin: Qingdao, China
Brand Name: Lehler
Certification: ISO9001:2015
Model Number: LSG-2100
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Plywood Case for Exporting Package
Delivery Time: 7 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 7 pieces 7 work days

Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification

Description
Name: Support Grid Dimension: 2100 Mm
Type: Wedge Wire Support Grid Material: SS304
Slot: 0.25 Mm Application: Pharmaceutical Industry
High Light:

distillation column internals

,

liquid distributor packed column

Wedge Wire Support Grid / Catalyst Support Grid



1. Lehler Support Grid



Flat, framed and unframed support grid can be manufactured with rectangular or round support rods.

Support Grid magnify vibration with drum-tight tension and withstand violent vibrating action.

Profile wire Support Rod
0.75*1.5mm 2*3mm
1.0*2.0mm 2*3mm
2.0*3.0mm 3*5mm
2.0*4.0mm 3*5mm
3.0*5.0mm 3*5mm



2.Features and benefits:

Large open slots increase screening efficiency and promote precise sizing.

The design enhances efficiency by substantially reducing blinding and pegging.



3.Details pictures of Lehler Sieve Bend Screen

Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification 0Wedge Wire Catalyst Support Grid With Large Open Slots ISO9001:2015 Certification 1

4. Application of Lehler Support Grid?

  • Aggregate

  • Dewatering

  • Chemical application include fertilizer

  • Mining Application include coal, potash, taconite, sand and gravel

  • Food application include potatoes, vegetables, sugar, cornstarch and cereal.

  • For application where sizing accuracy is critical. Ideal for reducing blinding and pegging

5. Advantages of Support Grid?

  1. Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
  2. Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
  3. Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
  4. High-precision slot opening: Minimum Slot opening is 20 microns.
