High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate

High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate
High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate

Large Image :  High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate

Product Details:
Place of Origin: Qingdao, China
Brand Name: Lehler
Certification: ISO9001:2015
Model Number: LSG-1800
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Plywood Case for Exporting Package
Delivery Time: 7 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 7 pieces 7 work days

High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate

Description
Name: Support Grid DIA: 1800 Mm
Type: Sintered Mesh Material: SS316L
Slot: 5 Micron Application: Chemical Industry
Highlight:

liquid distributor packed column

,

column internal trays

High filtration rate 5 micron Sintered Mesh Support Grid / Catalyst Support Grid



1. Lehler Support Grid



Flat, framed and unframed support grid can be manufactured with rectangular or round support rods.

Support Grid magnify vibration with drum-tight tension and withstand violent vibrating action.

Profile wire Support Rod
0.75*1.5mm 2*3mm
1.0*2.0mm 2*3mm
2.0*3.0mm 3*5mm
2.0*4.0mm 3*5mm
3.0*5.0mm 3*5mm



2.Features and benefits:

Large open slots increase screening efficiency and promote precise sizing.

The design enhances efficiency by substantially reducing blinding and pegging.



3.Details pictures of Lehler Sieve Bend Screen



High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate 0High Filtration Rate sintered mesh Internals , 5 Micron Ssintered mesh plate 1



4. Application of Lehler Support Grid?

  • Aggregate

  • Dewatering

  • Chemical application include fertilizer

  • Mining Application include coal, potash, taconite, sand and gravel

  • Food application include potatoes, vegetables, sugar, cornstarch and cereal.

  • For application where sizing accuracy is critical. Ideal for reducing blinding and pegging

5. Advantages of Support Grid?

  1. Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
  2. Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
  3. Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
  4. High-precision slot opening: Minimum Slot opening is 20 microns.
