Double V Wire Screen With Smooth Filtration Surface ISO Certification

Double V Wire Screen With Smooth Filtration Surface ISO Certification
Double V Wire Screen With Smooth Filtration Surface ISO Certification Double V Wire Screen With Smooth Filtration Surface ISO Certification

Large Image :  Double V Wire Screen With Smooth Filtration Surface ISO Certification

Product Details:
Place of Origin: Qingdao, China
Brand Name: Lehler
Certification: ISO9001:2015
Model Number: WWS-025
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Plywood Case for Exporting Package
Delivery Time: 7 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 pieces 7 work days

Double V Wire Screen With Smooth Filtration Surface ISO Certification

Description
Product: Wire Screen Slot: 1.0 Mm
Structure: From Inside To Outside Profile Wire: Vertical
Support Rod: Circular Type: Double Screens
High Light:

wedge wire grate

,

metal wire screen

Double Wire Screen / Double Wedge Wire Dewatering Screens / Drain Screens



1. Double Wire Screen Brife Introduction:

Wedge Wire is produced through the method of electric resistance welding, wires with special profiles are welded to supporting wires at 90 degrees.

Wedge Wire is characteristic of accurate cut size and precise gap (aperture) required with the ability to carry heavy loads.

The working surface is 100% smooth which eliminates blinding and pegging.

The distance between the surface profiles is controlled very accurately as it forms the slot through which the filtrate flows.

The direction of the flow is determined by the position of the surface profiles in relation to the support profiles.

Wedge wire screens are either flow-out-to-in OR flow-in-to-out.



2.Specification of Lehler wedge wire screen?

  • Minimum slot: 0.02mm(20um)
  • Mimimum diameter: 16mm
  • Maxmum Length: 6000mm
  • Perfect roundness
  • Very smooth wire surface
Profile wire Support Rod
0.75*1.5mm 2*3mm
1.0*2.0mm 2*3mm
2.0*3.0mm 3*5mm
2.0*4.0mm 3*5mm
3.0*5.0mm 3*5mm



3.Details pictures of Lehler wedge wire screen

Double V Wire Screen With Smooth Filtration Surface ISO Certification 0

Double V Wire Screen With Smooth Filtration Surface ISO Certification 1Double V Wire Screen With Smooth Filtration Surface ISO Certification 2

4. Application of wedge wire screen?

  • Waste water treatment
  • Petrochemical
  • Coatings
  • Mineral and aggregate processing
  • Pulp and paper
  • Chemical
  • Solid-liquid separation
  • Food and beverage

5. Advantages of wedge wire screen?

  1. Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
  2. Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
  3. Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
  4. High-precision slot opening: Minimum Slot opening is 20 microns.
