Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening

Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening

    • Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening
    • Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening
  • Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening

    Product Details:

    Place of Origin: Qingdao, China
    Brand Name: Lehler
    Certification: ISO9001:2015
    Model Number: SBS-1727

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Negotiable
    Packaging Details: Plywood Case for Exporting Package
    Delivery Time: 7 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 10 pieces per 7 work days
    Contact Now
    Detailed Product Description
    Product Name: Sieve Bend Screen Application: Pulp And Paper Industry
    Material: SS316L Dimension: 710x1727 Mm
    Frame: L-Shape Slot: 150 Micron
    High Light:

    stainless steel sieve screen

    ,

    stainless steel sieve mesh

    Pulp and Paper Industry Wedge Wire Sieve Bend Screen for Dewatering and Recovery



    1. Wedge Wire Sieve Bend Screen is widely used for Pulp and paper industries.

    Lehler Sieve Bend Screens is a pre-filter to improve the performance of the clarifier by drastically reducing the load.

    A curved screen has greater capacity than a flat screen due to forces exerted as material flows against the curved surface.



    2.Specification of Lehler Sieve bend Screen?

    Profile wire Support rod
    0.76x1.5mm 2.0x3.0mm
    1.5x2.5mm 2.0x3.0mm
    2.0x3.0mm 3.0x5.0mm
    2.0x4.0mm 3.0x5.0mm
    2.5x3.0mm 3.0x5.0mm
    3.0x5.0mm 3.0x5.0mm
    3.0x6.0mm 5.0x8.0mm


    3.Details pictures of Sieve bend Screen:

    Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening 0

    Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening 1Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening 2

    Pulp / Paper Industry Sieve Bend Screen 710*1727mm High - Precision Slot Opening 3

    4. Application of Sieve bend Screen?

    • Used in static sieves, our sieve screens can be manufactured in flat, curved, and cylindrical styles based on your Application.

    • Used for dewatering. Aggregate and mining applications include coal, potash, taconite, sand or gravel. Chemical applications included fertilizer. Food applications include potatoes, other vegetables, sugar, cornstarch, and cereal.

    5. Advantages of Sieve bend Screen?

    • Non-clogging construction: The v-shaped wires and support rods is welded together by automatic resistance welding, which ensures a two- point contact between the particles and the slot,which minimizes clogging of near size product.
    • Strong construction: for most applications the wedge wire is self-supporting because of the welding at each intersection and can therefore withstand high pressure(Psi) and heavy loads.
    • Smooth Surface Filtration: very good smooth filtration surface, which reduce mechanical wear.
    • High-precision slot opening: Minimum Slot opening is 20 microns.
